Carida DMX Dimmable 600x600 LED Panel 30w - 4000K

This one-of-a-kind 600x600 LED Panel in 4000K Cool White is designed for use in DMX Dimming systems (Digital Multiplex) often found in Entertainment and Stage, Architectural, Commercial, Smart Home and Specialised Lighting Setups, but not limited to. 100002-DMX DMX LED Driver Datasheet Download Here

Speak to Sales

Looking for bulk prices or need some help?

Phone 0113 518 8886

Availability :
In Stock

£137.00 Excl. VAT£115.00 Excl. VAT

MPN :
100002-DMX

110+ Sold

Carida DMX Dimmable 600×600 LED Panel 30W – 4000K


This one-of-a-kind 600x600 LED Panel in 4000K Cool White is designed for use in DMX Dimming systems (Digital Multiplex) often found in Entertainment and Stage, Architectural, Commercial, Smart Home and Specialised Lighting Setups, but not limited to. Partcode: 100002-DMX


Features:


DMX512 compliant control interface

RDM function enabled to realise intercommunication DMX master and decoder

DMX decoder's address can be assigned by DMX master console

DMX channel quantity from 1CH ~ 2CH settable

Output PWN frequency 500Hz ~ 2000Hz

Output dimming curve gamma value from 0.1 ~ 9.9 settable

For full driver specifications | Download Datasheet

Please note before ordering this item: this product should NOT be confused with regular mains dimming, dali dimming, 0-10v and 1-10v dimming. If you need help identifying which type of dimming you require, please ask before ordering as this product requires advanced knownledge during installing or when upgrading your old lighting utilising a DMX dimming system.

DMX Dimming is often used in Entertainment and Stage, Architectural, Commercial, Smart Home and Specialised Lighting environments.

Unidirectional: DMX is a one-way protocol, meaning the controller sends instructions to the lights, but the lights do not send data back (unlike modern bidirectional protocols like DALI)

DMX was introduced in the 1980s by USITT (United States Institute for Theatre Technology) to provide a standardised, cost-effective method to make lighting gear from different manufacturers work together. However, it is still present in many applications across the globe to this day.

Until now, nobody has made a compatible 600×600 LED Panel that is DMX Dimming compatible. We have tested this setup robustly before bringing it to market. We can also make other LED luminaires DMX dimmable. Please ask for further information.

Delivery Fees:

→ FREE Express Delivery when you spend £40.00+VAT or more. Express Delivery for orders under £40.00+VAT is £4.99+VAT.

Orders in stock placed before 4:00 PM Monday – Thursday (3:30 PM Friday) will be dispatched the same day and delivered within 1-2 working days (Monday – Friday *excluding weekends). All orders are tracked and insured, covering any unlikely loss or damage.

Orders are packaged and dispatched from our warehouse facility in Leeds, West Yorkshire, United Kingdom. We can also upgrade shipments to Pre-12:00 PM or Saturday Delivery on Friday Shipments, for example, but please call us on 0113 518 8886 and place the order over the phone instead.

Collection:

You may collect your goods from our trade counter located at Unit B8, Astra Business Park, Parkside Lane, Leeds LS11 5SZ, but please make sure to add a note at checkout saying you’re collecting your order. If your order is under £40.00+VAT, please call and place your order over the phone to remove the shipping charge. Someone in our customer support team will advise on your collection date and time. Please make sure you have a time confirmation before travelling.

Please note: Items on backorder will be sent out as soon as the stock is available. Orders placed after 3:30 PM on Friday and over the weekend will be dispatched on Monday. Orders placed on Bank holidays will be processed as normal, but dispatch will be the next working day.


Returns:

Enjoy up to 60 days to return any unused items.

Please see your returns paperwork (which may be affixed or inside your parcel) for instructions. You can find out more by visiting our delivery and returns page. We can also book a return for you. Please contact us on 0113 518 8886 to arrange.

Refunds are issued within 7 days of receiving the goods. Normally, within 3 days of receiving the goods.

Please see our Terms & Conditions page.

Technical Specifications

Feature Detail
Wattage 30w
Lumens 3600lm
Led Spec SMD2835/48
UGR 22
Colour Ra >80
Input Voltage 200-240v/50hz
Driver Included Yes (includes male/female jack plugs)
Driver Max Current 250 - 700 mA
Dimmable Yes - DMX Dimming ONLY
Dimming Range 0.1 ~ 100%
Driver Working Voltage 8-48v
Warranty 5 Years

Specialist DMX Dimmable LED Panel

We can also supply these DMX Panels in warm white and daylight colour temperatures. Please call us or ask via the online chat for a POA
